| DIMENSIONS | |
| Total length unfolded | 2100 mm |
| Total width (excluding joints) | 1016 mm |
| Minimum height including the upholstering | 600 mm |
| MANUAL ADUJSTMENT | |
| Angle adjustment of the leg rest | 0° / +25° |
| Height adjustment of the leg rest | 225 mm |
| Horizontal extension of the leg rest | +0°, 60°, 90° |
| Leg position adjustment |
| MOTORIZED POSITIONING | |
| Maximum elevation at height adjustment | 295 mm |
| Angle adjustment of the backrest * | -12° / +70° |
| Angle adjustment of the seat | 0° / +20° |
*In case of power failure or during breakdown of the backrest motorised mechanism it is possible to set the backrest into anti-shock position manually.
| MAXIMUM LOAD | |
| Maximum load for the loading area | 210 kg |
| ELECTRICAL PARAMETERS | |
| Standby accumulators | 1,2 Ah |
| Voltage – input | 100-230 V |
| Frequency | 50/60 Hz |
| Medical Device Classification | BF |
| Device class | I |
| Protection | IP X4 |
